DS-2CE76U1T-ITMF

Camera Image Sensor 8.29 megapixel progressive scan CMOS Signal System PAL/NTSC Frame Rate TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps CVI: 8MP@12.5fps, 8MP@15fps AHD: 8M@12.5fps, 8M@15fps CVBS: 960H P/N Resolution 3840 (H) × 2160 (V) Min. Illumination Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/12.5 s to 1/50,000 s NTSC: 1/15 s to 1/50,000 s Lens 2.8 mm, 3.6 mm, 6 mm fixed lens Horizontal Field of View 102.2°(2.8 mm), 79° (3.6 mm), 50.8° (6 mm) Lens Mount M16 Day & Night IR cut filter Angle Adjustment (Bracket) Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360° Synchronization Internal synchronization DWDR (Digital Wide Dynamic Range) 105 dB Menu AGC Yes Day/Night Mode Auto/Color/BW (Black and White) White Balance Auto/Manual BLC (Backlight Compensation) Yes Language English Functions Brightness, Sharpness, DNR, Smart IR, HLC Interface Video Output 1 HD analog output Switch Button TVI/AHD/CVI/CVBS General Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Power Supply 12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera. Power Consumption Max. 5.3 W Protection Level IP67 Material Metal IR Range Up to 30 m Communication Up the coax, Protocol: HIKVISION-C (TVI output) Dimensions 90 mm × 79.37 mm (3.54" × 3.12" ) Weight Approx. 310 g (0.68 lb.
